Wireless Torque Monitoring With Torque-Link

發(fā)布時間：2018-11-21 瀏覽次數(shù)：4991 來源：歐美大地

Why monitor torque?

Predict system degradation
Monitor overload conditions
Ensure proper rotor/engine load balancing
Analyze driveline resonance
Perform root cause analysis of machine failures
Provide accurate feedback for flight controls
Determine health of vital rotating components

LORD Sensing’s Torque-Link:

Is easy to install and integrate
Transmits torque data wirelessly
Allows remote node configuration
Uses unobtrusive, lightweight hardware
Eliminates need for slip rings
Is ideal for high-RPM applications
Meets DO-160 standards for temp and vibration

TORQUE-LINK-LXRS

Specifications

Single differential analog input channel (two-channel option available)
Fits 2”-6” shafts (custom sizes also available)
±32 μsec node-to-node synchronization
Requires 3.5” minimum axial length
Continuous sampling up to 512 Hz
-40° C to 80° C temperature range
Custom-engineered ABS thermoplastic housing
Weighs as little as 200 grams
Low power consumption / replaceable batteries

Torque-Link Applications

Flight Testing:
LORD Sensing’s Torque-Link has been used successfully by several companies in flight test applications. Instead of relying on bulky, unreliable slip rings that require hours to install, engineers were able to quickly install Torque-Link nodes and connect it to a wireless system for fast and accurate torsional strain measures.

Off-Highway Vehicles:
The limitations of slip rings is perhaps most apparent on the proving grounds for off-highway vehicles. During development tests, slip rings may last only 100-200 hours before failure, while the Torque-Link wireless node has been proven to endure for more than 1,000 hours. In addition, removing a failed slip ring may require several hours. A Torque-Link, meanwhile, requires less than five minutes for removal, battery replacement, and re-installation.

Rotating Machinery Analysis:
Engineers performing root-cause analysis for rotating machinery failures use the Torque-Link in burst mode (up to 4 kHz) due the higher frequency required for analysis of torsional vibration and driveline resonance. In the field, a system of more than ten Torque-Links has been used by a company to analyze how driveline resonance caused driveshaft failures on fracking pump trucks. LORD Sensing’s Torque-Link technology successfully analyzed the situation and provided a damping solution.

Condition-Based Maintenance:
Many companies currently rely on accelerometers and thermocouples to measure bearing vibration, pump vibration, machinery vibration, and temperature. Using a LORD Sensing Torque-Link not only accomplishes the same goals but also increases accuracy and can also identify other issues-- helping to more fully diagnose failures and plan maintenance cycles, which can, in turn, save up to $1 million per hour that would have been lost during unplanned maintenance downtime.
