Model:Coating Tape for Reinforcing Bar
Use:Coating tape for reinforcing bar
This tape is specially designed for use as a waterproof coating for strain gauges bonded onto reinforcing bars or other cylindrical surfaces. Coating is achieved by simply taping it onto the surface, saving considerable time in comparison with conventional procedures. (A heat gun is required for application.)
Type |
Applicable reinforcing bar |
Quantity per box |
Applicable strain gauges |
Size finish (example) |
|
Reinforcing bar |
Diameter |
||||
CT-D04 |
D4 |
10 |
FLK-2-11 |
D4 |
Φ10 x 21 |
CT-D06 |
D6 |
10 |
FLK-2-11 |
D6 |
Φ12 x 21 |
CT-D10 |
D10 |
10 |
FLK-2-11 |
D10 |
Φ15 x 21 |
CT-D13 |
D13 |
10 |
FLA-3-11 |
D13 |
Φ19 x 26 |
CT-D16 |
D16 |
10 |
FLA-3-11 |
D16 |
Φ21 x 26 |
CT-D25 |
D19 to D25 |
10 |
FLA-3-11 |
D25 |
Φ31 x 31 |
CT-D35 |
D29 to D35 |
10 |
FLA-3-11 |
D32 |
Φ37 x 35 |
